VHF55-12IO7
| Part Number | VHF55-12IO7 |
|---|---|
| Description | RECT BRIDGE 1PH 1200V FO-T-A |
| Category | Discrete Semiconductor Products |
| Manufacturer | IXYS Corporation |
| In Stock | 16173 |
| Datasheet | Download |
Description
| Manufacturer | IXYS Corporation |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Off State | 1.2kV |
| Voltage – Gate Trigger (Vgt) | 1.5V |
| Structure | Bridge, Single Phase – SCRs/Diodes (Layout 1) |
| Packaging | Bulk |
| Package / Case | FO-T-A |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs, 2 Diodes |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Detailed Description | SCR Module 1.2kV Bridge, Single Phase – SCRs/Diodes (Layout 1) Chassis Mount FO-T-A |
| Current – On State (It (AV)) (Max) | 53A |
| Current – Surge 50 60Hz Itsm | 550A, 600A |
| Current – Hold (Ih) (Max) | 200mA |
| Current – Gate Trigger Igt | 100mA |
| Base Part Number | VHF55 |
