UPG2181T5R-E2-A

Part Number	UPG2181T5R-E2-A
Description	IC SW DP4T 2.3-3.8GHZ 20 RQFN
Category	RF/IF and RFID
Manufacturer	CEL (California Eastern Laboratories)
In Stock	19559
Datasheet	Download

Category: RF/IF and RFID

Description

Description

Manufacturer	CEL (California Eastern Laboratories)
Lead / RoHS Status	Lead free / RoHS Compliant
Voltage – Supply	2.8 V ~ 3.2 V
Topology	Reflective
Test Frequency	3.8GHz
Supplier Device Package	20-RQFN (3.5×2.5)
RF Type	WiMax
Packaging	Tape & Reel (TR)
Package / Case	20-UFQFN Exposed Pad
P1dB	35dBm
Operating Temperature	-45°C ~ 85°C
Moisture Sensitivity Level	1 (Unlimited)
Isolation	22dB
Insertion Loss	1dB
Impedance	50 Ohm
Frequency Range	2.3GHz ~ 3.8GHz
Detailed Description	RF Switch IC WiMax DP4T 3.8GHz 50 Ohm 20-RQFN (3.5×2.5)
Circuit	DP4T
