SSW-131-02-T-D

Part Number

Description

Manufacturer	Samtec, Inc.
Lead / RoHS Status	Lead free / RoHS Compliant
Termination	Solder
Style	Board to Board or Cable
Series	SSW
Row Spacing – Mating	0.100″ (2.54mm)
Pitch – Mating	0.100″ (2.54mm)
Packaging	Bulk
Other Names	SAM1221-31
Operating Temperature	-55°C ~ 105°C
Number of Rows	2
Number of Positions Loaded	All
Number of Positions	62
Mounting Type	Through Hole
Material Flammability Rating	UL94 V-0
Insulation Material	Liquid Crystal Polymer (LCP)
Insulation Height	0.335″ (8.51mm)
Insulation Color	Black
Fastening Type	Push-Pull
Detailed Description	62 Position Receptacle Connector 0.100″ (2.54mm) Through Hole Tin
Current Rating	5.7A per Contact
Contact Type	Forked
Contact Shape	Square
Contact Material	Phosphor Bronze
Contact Length – Post	0.194″ (4.93mm)
Contact Finish – Post	Tin
Contact Finish – Mating	Tin
Connector Type	Receptacle

Description
