PZC15SAEN
| Part Number | PZC15SAEN |
|---|---|
| Description | CONN HEADER .100 SINGL STR 15POS |
| Category | Connectors |
| Manufacturer | Sullins Connector Solutions |
| In Stock | 6018 |
| Datasheet | Download |
Description
| Manufacturer | Sullins Connector Solutions |
|---|---|
| Lead / RoHS Status | Contains lead / RoHS non-compliant |
| Termination | Solder |
| Style | Board to Board or Cable |
| Shrouding | Unshrouded |
| Pitch – Mating | 0.100″ (2.54mm) |
| Packaging | Bulk |
| Overall Contact Length | 0.850″ (21.59mm) |
| Other Names | S1051-15 |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 15 |
| Mounting Type | Through Hole |
| Material Flammability Rating | UL94 V-0 |
| Insulation Material | Thermoplastic, Polyester |
| Insulation Height | 0.100″ (2.54mm) |
| Insulation Color | Black |
| Fastening Type | Push-Pull |
| Detailed Description | Connector Header Through Hole 15 position 0.100″ (2.54mm) |
| Current Rating | 3A |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Copper Alloy |
| Contact Length – Post | 0.520″ (13.21mm) |
| Contact Length – Mating | 0.230″ (5.84mm) |
| Contact Finish Thickness – Post | 100.0µin (2.54µm) |
| Finish Thickness – Mating | 10.0µin (0.25µm) |
| Contact Finish – Post | Tin |
| Contact Finish – Mating | Gold |
| Connector Type | Header |
