NREC006SAEN-RC
| Part Number | NREC006SAEN-RC |
|---|---|
| Description | CONN HEADER .100″ SNGL STR 6POS |
| Category | Connectors |
| Manufacturer | Sullins Connector Solutions |
| In Stock | 14877 |
| Datasheet | Download |
Description
| Manufacturer | Sullins Connector Solutions |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Termination | Solder |
| Style | Board to Board or Cable |
| Shrouding | Unshrouded |
| Pitch – Mating | 0.100″ (2.54mm) |
| Packaging | Bulk |
| Overall Contact Length | 0.848″ (21.55mm) |
| Other Names | S1152EC-06 S9517E-06 S9517E-06-ND |
| Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 6 |
| Mounting Type | Through Hole |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 |
| Insulation Material | Polyamide (PA6T), Nylon 6T |
| Insulation Height | 0.098″ (2.50mm) |
| Insulation Color | Black |
| Fastening Type | Push-Pull |
| Detailed Description | Connector Header Through Hole 6 position 0.100″ (2.54mm) |
| Current Rating | 3A per Contact |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Brass |
| Contact Length – Post | 0.520″ (13.21mm) |
| Contact Length – Mating | 0.230″ (5.84mm) |
| Contact Finish – Post | Tin |
| Contact Finish – Mating | Tin |
| Connector Type | Header, Breakaway |
