MSTC90-12
| Part Number | MSTC90-12 |
|---|---|
| Description | MOD THYRISTOR DIODE 90A SF1 |
| Category | Discrete Semiconductor Products |
| Manufacturer | Microsemi |
| In Stock | 16387 |
| Datasheet | Download |
Description
| Manufacturer | Microsemi |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Off State | 1.2kV |
| Voltage – Gate Trigger (Vgt) (Max) | 3V |
| Structure | Series Connection – All SCRs |
| Packaging | Bulk |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 130°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs |
| Mounting Type | Chassis Mount |
| Detailed Description | SCR Module 1.2kV Series Connection – All SCRs Chassis Mount Module |
| Current – On State (It (AV)) (Max) | 90A |
| Current – Hold (Ih) (Max) | 250mA |
| Current – Gate Trigger (Igt) (Max) | 150mA |
