LEG120W-171-C0700-D

Part Number	LEG120W-171-C0700-D
Description	LED DRIVR CC AC/DC 57-171V 700MA
Category	Power Supplies – External/Internal (Off-Board)
Manufacturer	Thomas Research Products
In Stock	15046
Datasheet	Download

Description

Manufacturer	Thomas Research Products
Lead / RoHS Status	Lead free / RoHS Compliant
Weight	1.7 lbs (771.1g)
Voltage – Output	57 ~ 171 V
Voltage – Input (Min)	120VAC
Voltage – Input (Max)	277VAC
Type	Constant Current
Topology	AC DC Converter
Termination Style	Wire Leads
Size / Dimension	9.47″ L x 1.80″ W x 1.32″ H (240.5mm x 45.8mm x 33.5mm)
Series	LEG-120W
Ratings	IP66
Power (Watts)	120W
Other Names	Q9481743
Number of Outputs	1
Mounting Type	Chassis Mount
Features	OCP, OVP, SCP
Efficiency	90%
Dimming	Analog
Detailed Description	700mA 57 ~ 171 V Constant Current LED Driver AC DC Converter Topology 1 Output
Current – Output (Max)	700mA
California Prop 65	Warning Information WARNING: This product can expose you to chemicals including Lead and lead compounds which is known to the State of California to cause cancer and birth defects or other r
Approvals	CE, cURus
