KAR08LHGT
Description
| Manufacturer | E-Switch |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Washable | Yes |
| Voltage Rating | 24VDC |
| Termination Style | PC Pin |
| Series | KAR |
| Pitch | 0.100″ (2.54mm), Full |
| Packaging | Tube |
| Operating Temperature | -30°C ~ 85°C |
| Number of Positions | 8 |
| Mounting Type | Through Hole, Right Angle |
| Mechanical Life | 2,000 Cycles |
| Length | 0.890″ (22.61mm) |
| Height Above Board | 0.293″ (7.45mm) |
| Features | Process Sealed |
| Detailed Description | Dip Switch SPST 8 Position Through Hole, Right Angle Piano Actuator 25mA 24VDC |
| Current Rating | 25mA |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Circuit | SPST |
| Body Material | Polyphenylene Sulfide (PPS) |
| Actuator Type | Piano |
| Actuator Level | Raised |
