IXFC15N80Q
| Part Number | IXFC15N80Q |
|---|---|
| Description | MOSFET N-CH 800V 13A ISOPLUS220 |
| Category | Discrete Semiconductor Products |
| Manufacturer | IXYS Corporation |
| In Stock | 17448 |
| Datasheet | Download |
Description
| Manufacturer | IXYS Corporation |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Vgs(th) (Max) @ Id | 4.5V @ 4mA |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | ISOPLUS220 |
| Series | HiPerFET |
| Rds On (Max) @ Id, Vgs | 650 mOhm @ 500mA, 10V |
| Power Dissipation (Max) | 230W (Tc) |
| Packaging | Tube |
| Package / Case | ISOPLUS220 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance @ Vds | 4300pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 90nC @ 10V |
| Drive Voltage (Max/Min Rds) | 10V |
| Drain to Source Voltage (Vdss) | 800V |
| Detailed Description | N-Channel 800V 13A (Tc) 230W (Tc) Through Hole ISOPLUS220 |
| Current – Drain (Id) @ 25°C | 13A (Tc) |
