IRKT105/16A
| Part Number | IRKT105/16A |
|---|---|
| Description | SCR DBL HISCR 1600V 105A ADDAPAK |
| Category | Discrete Semiconductor Products |
| Manufacturer | Electro-Films (EFI) / Vishay |
| In Stock | 17451 |
| Datasheet | Download |
Description
| Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|
| Lead / RoHS Status | Contains lead / RoHS non-compliant |
| Voltage – Off State | 1.6kV |
| Voltage – Gate Trigger (Vgt) | 2.5V |
| Structure | Series Connection – SCR/Diode |
| Packaging | Bulk |
| Package / Case | ADD-A-PAK (3 + 4) |
| Other Names | *IRKT105/16A IRKT105/16 IRKT105/16-ND VS-IRKT105/16A VS-IRKT105/16A-ND VSIRKT105/16A VSIRKT105/16A-ND |
| Operating Temperature | -40°C ~ 130°C (TJ) |
| Number of SCRs, Diodes | 1 SCR, 1 Diode |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Detailed Description | SCR Module 1.6kV 235A Series Connection – SCR/Diode Chassis Mount ADD-A-PAK (3 + 4) |
| Current – On State (It (RMS)) (Max) | 235A |
| Current – On State (It (AV)) (Max) | 105A |
| Current – Surge 50 60Hz Itsm | 1785A, 1870A |
| Current – Hold (Ih) (Max) | 200mA |
| Current – Gate Trigger Igt | 150mA |
| Base Part Number | KT105 |
