IRG7T100HF12A
| Part Number | IRG7T100HF12A |
|---|---|
| Description | MOD IGBT 1200V 100A POWIR 34 |
| Category | Discrete Semiconductor Products |
| Manufacturer | International Rectifier (Infineon Technologies) |
| In Stock | 12837 |
| Datasheet | Download |
Description
| Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Collector Emitter | 1200V |
| Vce(on) (Max) @ Vge, Ic | 2.2V @ 15V, 100A |
| Supplier Device Package | POWIR® 34 |
| Power – Max | 575W |
| Package / Case | POWIR® 34 Module |
| Other Names | SP001540680 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| NTC Thermistor | No |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance (Cies) @ Vce | 13.7nF @ 25V |
| Input | Standard |
| Detailed Description | IGBT Module Half Bridge 1200V 200A 575W Chassis Mount POWIR® 34 |
| Current – Collector Cutoff | 1mA |
| Current – Collector (Ic) (Max) | 200A |
| Configuration | Half Bridge |
