GTC15SBSN-M89
| Part Number | GTC15SBSN-M89 |
|---|---|
| Description | CONN HEADER 15POS .100 R/A SMD |
| Category | Connectors |
| Manufacturer | Sullins Connector Solutions |
| In Stock | 16384 |
| Datasheet | Download |
Description
| Manufacturer | Sullins Connector Solutions |
|---|---|
| Lead / RoHS Status | Contains lead / RoHS non-compliant |
| Voltage Rating | 600VDC |
| Termination | Solder |
| Style | Board to Board or Cable |
| Shrouding | Unshrouded |
| Pitch – Mating | 0.100″ (2.54mm) |
| Packaging | Bulk |
| Other Names | S1113-15 |
| Operating Temperature | -65°C ~ 125°C |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 15 |
| Mounting Type | Surface Mount, Right Angle |
| Material Flammability Rating | UL94 V-0 |
| Insulation Material | Polyamide (PA9T), Nylon 9T |
| Insulation Height | 0.140″ (3.56mm) |
| Insulation Color | Black |
| Fastening Type | Push-Pull |
| Detailed Description | Connector Header Surface Mount, Right Angle 15 position 0.100″ (2.54mm) |
| Current Rating | 3A |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Phosphor Bronze |
| Contact Length – Mating | 0.230″ (5.84mm) |
| Contact Finish Thickness – Post | 100.0µin (2.54µm) |
| Finish Thickness – Mating | 100.0µin (2.54µm) |
| Contact Finish – Post | Tin-Lead |
| Contact Finish – Mating | Tin-Lead |
| Connector Type | Header |
