ASMT-QTB2-0A002

Part Number	ASMT-QTB2-0A002
Description	LED RGB CLEAR 4PLCC SMD
Category	Optoelectronics
Manufacturer	Avago Technologies (Broadcom Limited)
In Stock	5562
Datasheet	Download

Part Number

Description

Manufacturer	Avago Technologies (Broadcom Limited)
Lead / RoHS Status	Lead free / RoHS Compliant
Wavelength – Peak	639nm Red, 519nm Green, 467nm Blue
Wavelength – Dominant	628nm Red, 526nm Green, 472nm Blue
Voltage – Forward (Vf) (Typ)	2.06V Red, 3.32V Green, 3.32V Blue
Viewing Angle	120°
Supplier Device Package	4-PLCC
Size / Dimension	3.60mm L x 3.20mm W
Packaging	Tape & Reel (TR)
Package / Case	4-SMD, No Lead
Other Names	ASMTQTB20A002
Mounting Type	Surface Mount
Moisture Sensitivity Level	2A (4 Weeks)
Millicandela Rating	505mcd Red, 1015mcd Green, 325mcd Blue
Lens Transparency	Clear
Lens Style/Size	Round with Flat Top, 2.90mm
Lens Color	Colorless
Height (Max)	2.20mm
Detailed Description	Red, Green, Blue (RGB) 628nm Red, 526nm Green, 472nm Blue LED Indication – Discrete 2.06V Red, 3.32V Green, 3.32V Blue 4-SMD, No Lead
Current – Test	20mA Red, 20mA Green, 20mA Blue
Configuration	Common Anode
Color	Red, Green, Blue (RGB)
Base Part Number	ASMT-Q*B2
