APTM120VDA57T3G
| Part Number | APTM120VDA57T3G |
|---|---|
| Description | MOSFET 2N-CH 1200V 17A SP3 |
| Category | Discrete Semiconductor Products |
| Manufacturer | Microsemi |
| In Stock | 10589 |
| Datasheet | Download |
Description
| Manufacturer | Microsemi |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
| Supplier Device Package | SP3 |
| Series | POWER MOS 7® |
| Rds On (Max) @ Id, Vgs | 684 mOhm @ 8.5A, 10V |
| Power – Max | 390W |
| Packaging | Bulk |
| Package / Case | SP3 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance @ Vds | 5155pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 187nC @ 10V |
| FET Type | 2 N-Channel (Dual) |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Detailed Description | Mosfet Array 2 N-Channel (Dual) 1200V (1.2kV) 17A 390W Chassis Mount SP3 |
| Current – Drain (Id) @ 25°C | 17A |
