APTGF530U120D4G
| Part Number | APTGF530U120D4G |
|---|---|
| Description | IGBT 1200V 700A 3900W D4 |
| Category | Discrete Semiconductor Products |
| Manufacturer | Microsemi |
| In Stock | 15305 |
| Datasheet | Download |
Description
| Manufacturer | Microsemi |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Collector Emitter | 1200V |
| Vce(on) (Max) @ Vge, Ic | 3.7V @ 15V, 600A |
| Supplier Device Package | D4 |
| Power – Max | 3900W |
| Package / Case | D4 |
| NTC Thermistor | No |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance (Cies) @ Vce | 37nF @ 25V |
| Input | Standard |
| IGBT Type | NPT |
| Detailed Description | IGBT Module NPT Single 1200V 700A 3900W Chassis Mount D4 |
| Current – Collector Cutoff | 5mA |
| Current – Collector (Ic) (Max) | 700A |
| Configuration | Single |
