APTGF50DU120TG
| Part Number | APTGF50DU120TG |
|---|---|
| Description | IGBT MODULE NPT DUAL SP4 |
| Category | Discrete Semiconductor Products |
| Manufacturer | Microsemi |
| In Stock | 18003 |
| Datasheet | Download |
Description
| Manufacturer | Microsemi |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Collector Emitter | 1200V |
| Vce(on) (Max) @ Vge, Ic | 3.7V @ 15V, 50A |
| Supplier Device Package | SP4 |
| Power – Max | 312W |
| Package / Case | SP4 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| NTC Thermistor | Yes |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance (Cies) @ Vce | 3.45nF @ 25V |
| Input | Standard |
| IGBT Type | NPT |
| Detailed Description | IGBT Module NPT Dual, Common Source 1200V 75A 312W Chassis Mount SP4 |
| Current – Collector Cutoff | 250µA |
| Current – Collector (Ic) (Max) | 75A |
| Configuration | Dual, Common Source |
