929800-01-10
| Part Number | 929800-01-10 |
|---|---|
| Description | CONN HEADER 10POS .100″ TIN |
| Category | Connectors |
| Manufacturer | 3M |
| In Stock | 18528 |
| Datasheet | Download |
Description
| Manufacturer | 3M |
|---|---|
| Lead / RoHS Status | Contains lead / RoHS non-compliant |
| Termination | Solder |
| Style | Board to Board |
| Shrouding | Unshrouded |
| Series | 929 |
| Pitch – Mating | 0.100″ (2.54mm) |
| Packaging | Bulk |
| Overall Contact Length | 0.318″ (8.08mm) |
| Other Names | 00054007816171 05400781617 5400781617 54007816171 80620060725 |
| Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 10 |
| Mounting Type | Through Hole |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 |
| Insulation Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Insulation Height | 0.115″ (2.92mm) |
| Insulation Color | Black |
| Fastening Type | Push-Pull |
| Detailed Description | Connector Header Through Hole 10 position 0.100″ (2.54mm) |
| Current Rating | 2.5A |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Copper Alloy |
| Contact Length – Post | 0.110″ (2.79mm) |
| Contact Length – Mating | 0.093″ (2.36mm) |
| Finish Thickness – Mating | 100.0µin (2.54µm) |
| Contact Finish – Mating | Tin-Lead |
| Connector Type | Header, Breakaway |
