74HCT2G86DP-Q100H
| Part Number | 74HCT2G86DP-Q100H |
|---|---|
| Description | IC GATE XOR 2CH 2-INP 8TSSOP |
| Category | Integrated Circuits (ICs) |
| Manufacturer | Nexperia |
| In Stock | 5710 |
| Datasheet | Download |
Description
| Manufacturer | Nexperia |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Supply | 4.5 V ~ 5.5 V |
| Supplier Device Package | 8-TSSOP |
| Series | 74HCT |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118″, 3.00mm Width) |
| Other Names | 9.35302E+11 |
| Operating Temperature | -40°C ~ 125°C |
| Number of Inputs | 2 |
| Number of Circuits | 2 |
| Mounting Type | Surface Mount |
| Logic Type | XOR (Exclusive OR) |
| Logic Level – Low | 0.8V |
| Logic Level – High | 2V |
| Detailed Description | XOR (Exclusive OR) IC 2 Channel 8-TSSOP |
| Current – Quiescent (Max) | 1µA |
| Current – Output High, Low | 4mA, 4mA |
| Base Part Number | 74HCT2G86 |
