2N7002WKX-13
| Part Number | 2N7002WKX-13 |
|---|---|
| Description | MOSFET N-CH 60V SOT323 |
| Category | Discrete Semiconductor Products |
| Manufacturer | Diodes Incorporated |
| In Stock | 6931 |
| Datasheet | Download |
Description
| Manufacturer | Diodes Incorporated |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | SOT-323 |
| Series | Automotive, AEC-Q101 |
| Rds On (Max) @ Id, Vgs | 7.5 Ohm @ 50mA, 5V |
| Power Dissipation (Max) | 200mW (Ta) |
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Input Capacitance @ Vds | 50pF @ 25V |
| FET Type | N-Channel |
| Drive Voltage (Max/Min Rds) | 5V, 10V |
| Drain to Source Voltage (Vdss) | 60V |
| Detailed Description | N-Channel 60V 115mA (Ta) 200mW (Ta) Surface Mount SOT-323 |
| Current – Drain (Id) @ 25°C | 115mA (Ta) |
