109E1748C502

Part Number	109E1748C502
Description	DC AXIAL FAN 172X51MM
Category	Fans
Manufacturer	Sanyo Denki
In Stock	7622
Datasheet	Download

Category: Fans

Description

Description

Manufacturer	Sanyo Denki
Width	51.00mm
Weight	1.7 lbs (771.1g)
Voltage Range	40.8 ~ 55.2VDC
Voltage – Rated	48VDC
Termination	2 Wire Leads
Static Pressure	1.237 in H2O (308.0 Pa)
Size / Dimension	Round – 172mm Dia
Series	Dyna Ace
RPM	4800 RPM
Power (Watts)	57.6W
Operating Temperature	14 ~ 140°F (-10 ~ 60°C)
Noise	60.0 dB(A)
Material – Frame	Aluminum
Fan Type	Tubeaxial
Current Rating	1.20A
Bearing Type	Ball
Approvals	CSA, TUV, UL
Air Flow	350.0 CFM (9.80m³/min)
